我们可以ODM/OEM多种规格高精密,防水性能,大功率电位器产品。产品广泛用于汽车电子、白色家电、黑色家电、智能家居、电子机械设备、智能办公设备、影音设备、智慧医疗、智能穿戴、军工等领域。
Electrical: | |||
Resistance Range | 1KΩ-10KΩ | ||
Resistance Tolerance | ±10% Standard | ||
End Resistance | <3Ω | ||
Resistance Taper | B | ||
Independent Linearity | ±0.5% | ||
Power Rating | 0.5W(70℃)0W(120℃) 2W | ||
Peak Noise (C.R.V.) | <2%Rn | ||
Dielectric Strength | 1000V 1minute | ||
Adjustment Travel | 90°120°200° 240° 300° 340° | ||
Insulation Resistance | 10M | ||
Resolution | Essentially infinite | ||
Maximum Input Voltage | 200VDC | ||
Environmental: | |||
Storage Temperature Range | -60℃~+125℃ | ||
Operating Temperature Range | -60℃~+125℃ | ||
Temperature coefficient | 500ppm/℃ | ||
Load Life | 70℃ 1,000h ΔR/R≤±10% | ||
Rotational Life | 1,000,000 times, ΔR/R≤±7% | ||
IP Range | IP25 | ||
Soldering Heat Resistance | (350℃ 3S)ΔR/R≤±2% | ||
Temperature Cycle | (-25℃,+85℃ 30min/each,5 cycles) ΔR/R≤±10% | ||
Vibration | 10-55Hz, 1.5mm amplitude, 3.directions ΔR/R≤±5% | ||
Mechanical: | |||
SIZE | SEE DRAWING | ||
Mechanical Travel | 220° 320° 360° | ||
Shaft Torque | 25~35gf·cm | ||
Stop Strength | …… | ||
Mounting Nut Torque | 15Kgf·cm | ||
Shaft Runout | 0.15mm | ||
Shaft End Play | (shaft length 30 mm)0.15mm | ||
Shaft Radial Play | 0.15mm | ||
Shaft Strength (push) | 125 N (12.75 kgf ) min. | ||
Shaft Strength (tensile) | 125 N (12.75 kgf ) min. | ||
Marking | …… | ||
Hardware. | Washer,Lockwasher, Nut |
